Offshore Pedestal Fixed Marine the Best Deck Cranes
Stiff boom cranes are most suitable for general cargo handling and for service on
board ships and offshore units where there is ample deck space. As lack of hydraulic
cylinder on the boom,the crane can’t extend and folded.Thanks to its simple structure,
compare to the knuckle boom crane and telescopic crane, it’s price and maintenance
cost is the lowest.
Please provide following necessary information,so we can quote right Model crane.
1. Crane SWL requested
2. Max. working radius of the crane
3. The crane is for hose handling or normal cargo
4. The crane will be used on ship, offshore plantform or fixed plantform (motor 380V
or 440V)
5. If you have any other special request for the crane, please advise us
Drawing of Offshore Pedestal Fixed Marine the Best Deck Cranes
Technical Parameters of Offshore Pedestal Fixed Marine the Best Deck Cranes
| Crane Type | Outreach(m) | Lifting capacity(kg) | Lifting moment(kNm) | Total Moment (kNm) | Pedestal Outer Diameter (mm) | Dead Weight (kg) |
| HC200 | 6-16 | 3.5-0.9 | 144-210 | 270 | 885 | 2.7-3.2 |
| HC400 | 6-16 | 5.6-1.7 | 288-336 | 424 | 885 | 3.2-3.7 |
| HC600 | 6-20 | 10-2.3 | 460-600 | 737 | 1095 | 4.4-5.5 |
| HC 900 | 6-20 | 14.2-3.2 | 640-852 | 1039 | 1325 | 5.9-7.0 |
| HC1200 | 6-24 | 19-3.5 | 840-1140 | 1409 | 1490 | 7.8-10.2 |
| HC1500 | 7-24 | 20.3-4.6 | 1104-1421 | 1765 | 1490 | 9.2-11.3 |
| HC1800 | 7-24 | 25.6-5.4 | 1296-1792 | 2202 | 1770 | 11.4-14.1 |
| HC3000 | 21 | 12.5 | 2625 | 3750 | 1775 | 24.8 |
| HCK220 | 27,5 | 20,0 | 2200 | 4000 | 1800 | 15.0 |
| HCK300 | 30.0 | 25.0 | 3000 | 5000 | 2065 | 17.5 |
| HCK400 | 32.0 | 30.0 | 4000 | 6300 | 2050 | 20.0 |
| HCK500 | 35.0 | 35.0 | 5000 | 8000 | 2240 | 25.0 |
| HCK800 | 40.0 | 50.0 | 8000 | 11500 | 2271 | 45.0 |
Production Flow
Certifications(Offshore Pedestal Fixed Marine the Best Deck Cranes)
Packaging&Delivery(Offshore Pedestal Fixed Marine the Best Deck Cranes)
Shipping details
♦ check all the items and packaged well before loading.
♦ You can check loading or send picture to you.
♦ After shipping make documents for you,like B/L,packing list,voice according
to your requirements.
Contact us
Miss Wang ---Foregin trademan
Hp: 0086-17521634863
Email: cindy@haoyogroup
OFFICE ADD: NO. 500, JIANYUNRD,PUDONG,SHANGHAI
FACTORY ADD: INDUSTRIAL PARK, CHANGSHU, JIANGSU
Web: www.haoyogroup.com
|
|
Offshore Pedestal Fixed Marine the Best Deck Cranes Marine Ship Crane Images
|
